NVME ENCLOSURE | COMBO (NGFF + NVME) – TYPE C

Features:

• Comply with SATA 3 specifications and comply with USB3.0 specifications.
• Support SATA NVME protocol, suitable for M2 (B Key/B+M Key/M Key) SSD.
• Support M.2 SSD, 22*30mm, 22*42mm, 22*60mm, 22*80mm solid state drives, (SSD hard drives are not included).
• The output speed depends on the type of SSD you use, SATA (6Gbps), NVME (10Gbps).
• Dual protocol uses two kinds of cables, Type-C to Type-A (5Gbps) and Type-C to Type-C (10Gbps).
• The aluminum alloy shell increases the heat dissipation area, which facilitates the heat dissipation of the hard disk during work and increases the life of the hard disk.
• Support UASP protocol.
• Easy to use, no need to drive.

Specifications:

• Material: Aluminum alloy
• Color: Black, Silver (optional)
• Main Control Chip: RTL9210B
• Output Interface: USB 3.1 TYPE-C
• Transmission Rate: 10Gbps
• Hard Disk Interface: M KEY, B&M KEY
• Support Protocol: Support NVME/NGFF Two Protocols
• Support M.2 Hard Disk Size: 2230/2242/2260/2280 Four Sizes
• Support Capacity: 2TB MAX
• Installation Method: Screw Fixed
• Support System: for Win/Linux/ Android
• Item Size: 120 * 30 * 8mm / 4.72 * 1.18 * 0.31in
• Item Weight: 37g / 1.31ounces
• Package Weight: 62g / 2.19ounces
• Package Size: 165 * 75 * 20mm / 6.5 * 2.95 * 0.79 inch

Installation Steps:
Use a screwdriver to unscrew the top screws and take out the PCB board.
Align the slots and install the SSD hard drive.
Tighten the screw at the bottom of the hard drive to fix the hard drive.
Put the installed hard disk into the hard disk box and close the top cover.

Packing List:
1 * M.2 nVME SSD NGFF USB Type-C Enclosure
